TG8000iSn (RV’s)

TG8000iSn (RV’s)

Model 6008208010 Categories ,
ModelTG3500iSn
Output(kVA)3.5
Voltage(V)220/110 V
Frenquency(Hz)50/60 Hz
Weight(Kgs)56 Kgs
Packing Size(mm)630*450*280



Inquiry Now

Contact Us

Generator Voltage (V) 220
Frequency (Hz) 50
Rated Power (kw) 7.5
Max Power (kw) 8.0
Power Outlets N/A
Power Factor 0.93
Phases Single
Fuel Tank Capacity (L) 24
Continuously Running Hours(75% Load) 7.5
Type Super Silent
Engine Model TG420
Type Forced Air Cooled, Single Cylinder, 4 Stroke, OHV
Engine Speed (rpm) 2800 – 3600 based on load
Displacement (cc) 420
Fuel Type Unleaded Gasoline / LPG
Gasoline Consumption 375g/kw.h
LPG Consumption 0.415kg/kw.h
Oil Type SAE15W – 40 or SAE 5W – 30
Oil Capacity (ml) 1100
Others Net/Gross Weight (kg) 95 /100
Dimention L x W x H(mm) 935*640*590
pcs/20GP/40GP/40HQ 78 / 159 / 159
Certification EPA / CE / ISO9001
