| Model | WD10000SQ |
| Output(kVA) | 10 kVA |
| Voltage(V) | 110/220 V |
| Frenquency(Hz) | 50/60 Hz |
| Weight(Kgs) | 200 Kgs |
| Packing Size(mm) | 1100*760*880 mm |
| Diesel generator:(AUCAN brand) | ||||
| Model | WD10000E | WD10000SQ | ||
| Type | Revolving Magnetic Field,Single Phase | Revolving Magnetic Field,Single Phase | ||
| Voltage Regulate | AVR | AVR | ||
| AC Frequency(Hz) | 60 | 50 | 60 | 50 |
| AC Output Voltage(V) | 110;120;110/220;120/240 | 220;230;115/230 | 110;120;110/220;120/240 | 220;230;115/230 |
| Cont.AC Output(VA) | 9000 | 8000 | 9000 | 8000 |
| Max.AC Output(VA) | 10000 | 8500 | 10000 | 8500 |
| DC Output(V/A) | 12/8.3 | 12/8.3 | ||
| Engine Model | WD195F | WD195F | ||
| Type | Single cylinder,Air-cooled,4-stroke;Vertical | Single cylinder,Air-cooled,4-stroke;Vertical | ||
| Starting System | Recoil/Electric | Recoil/Electric | ||
| Fuel Tank Capacity(L/gal) | 15 | 15/3.96 | ||
| Packing dimensions(mm/in.) | 770*540*700 | 940*560*760 | ||
| Net Weight(kg/lbs) | 150 | 160 | ||
| Per 20″ GP CNT | 84 | 72 | ||
| Per 40″ GP CNT | 176 | 144 | ||
